15 usage taboos and 22 execution points in cone crusher operation

Takeaway:Latest company news about 15 usage taboos and 22 execution points in cone crusher operationNow the cone crusher has become the main product in the crushing machinery, but the failures and losses caused by improper operation are increasing. In daily production, what cannot be done and what must be done? The following is a summary of 15 taboos and 22 key points that must be implemented in the use of cone crushers for your reference.

latest company news about 15 usage taboos and 22 execution points in cone crusher operation  0

15taboos

1. It is forbidden to cross iron.

2. It is forbidden to start and stop with materials.

3. It is forbidden to operate the machine with excessive current or low voltage.

4. It is forbidden to continue running when the machine has abnormal noise.

5. When the machine is forbidden to run, check and adjust the machine.

6. Eccentric feeding of the machine is prohibited.

7. It is forbidden to enter large pieces of material (exceeding the feeding size of the manual) into the crushing cavity.

8. It is forbidden to adjust the ring to jump, and the discharge opening should be adjusted when it jumps.

9. It is forbidden to run the cone crusher when the lock nut of the adjusting seat is not locked.

10. It is forbidden to adjust the discharge opening with materials.

11. It is forbidden to run the cone crusher when the oil level of the lubrication station is low.

12. It is forbidden to run the cone crusher when the lubricating oil temperature is lower than 25℃.

13. It is forbidden to run the cone crusher when the lubricating oil return temperature is higher than 55℃, but the oil pump must keep running.

14. It is forbidden to run the cone crusher when the lubricating oil filter is blocked.

15. It is forbidden to operate the cone crusher when the alarm light on the lubrication station is on.

latest company news about 15 usage taboos and 22 execution points in cone crusher operation  1

22 implementation points

1. The center feeding must be continuous and uniform, and full feeding can improve work efficiency. (Per shift)

2. Check whether there are copper and iron filings on the oil return filter. (Per shift)

3. Check the oil level of the lubricating oil. (Per shift)

4. Check and record the pressure of the lubrication system and hydraulic system, and check whether the filter element is blocked. (Per shift)

5. Check the wear condition of the liner. (Per shift)

6. Check the condition of all bolts and their fasteners. (Per shift)

7. Check the contamination of lubricating oil. (Per shift)

8. Check whether the discharging area is unobstructed, and remove the accumulated material and debris on the rack. (Per shift)

9. Fill the adjusting ring with grease when the adjusting ring is not locked. (weekly)

10. Check and tighten the V-belt. (weekly)

11. Check and deal with all pipelines to avoid oil leakage. (weekly)

12. Check and tighten the bolts of the distributor. (weekly)

13. Check the electrical chain of the cone crusher and lubrication station. (weekly)

14. During the operation of the equipment, check whether the individual shock-absorbing blocks at the bottom are suspended due to the sinking of the foundation or the deformation of the steel frame, and the machine swings greatly due to no force. (weekly)

15. Check the pressure of the accumulator. (weekly)

16. Check and repair the frame guard plate and rib guard plate. (Replace the liner every time)

17. Check the wear condition of the spherical tile. (Replace the liner every time)

18. Check the wear condition of the taper sleeve and straight sleeve. (Replace the liner every time)

19. Check the wear condition of the upper friction disc. (Replace the liner every time)

20. Check the wear condition and clearance of the bevel gear. (Replace the liner every time)

21. Check the oil number and oil quantity of the lubrication station. (Periodic inspection)

22. Check the oil inlet oil pressure, oil flow rate, oil temperature (not lower than 25°C), return oil temperature (not exceeding 55°C), pressure data of the locking cylinder and the safety cylinder after the lubrication station is started.

Remarks: each shift is 8 hours of machine work
